Size
1/2” up to 24”
Temperature
Down to -196ºC
Pressure
150 lbs up to 2500 lbs
Standards
API, BS, MSS, ANSI, ASME, ASTM, DIN
Materials
CF3, CF3M, CF8, CF8C, CF8M, 316, 316L, 304, 304L…
Seals
Seats:
-
Gaskets:
-
O-ring:
-
End connections
BW, RF, FF, NPT, RTJ, SW; CLAMPS
Other technical features
‘- Trunnion or Floating type
– Full or reduced bore
– Different pressure relief systems and seat design configurations: DBB, DIB-1, DIB-2 and Relief Hole-DPE
– Two balls one body option also available
– Actuators: pneumatic, electric, hydraulic, pneumo-hydraulic, HIPPS…
– Fire Safe certified according API-6FA / API 607
– Fugitive Emission as per ISO 15848 Part 1&2 up to Class A
– Bonnet length (BS 6364 -Non-cold box or Cold-box-, ISO 28921-1 or MSS SP 134) and collar drip upon request
– Pup pieces option also available
Actuation
ACTUATOR, GEARBOX, LEVER, HANDWHEEL
Industries
Energy, Low Carbon Energies, LNG, Hydrogen, Chemical And Petrochemical, Gas Processing and transportation, Energy transition, Synthetic Fuels
